| Items | Units | Model：TV-500 | | Travel&accuracy |
| | X-axis | mm | 500 | | Y-axis | mm | 400 | | Z-axis | mm | 310 | | Fast feedof X&Y axis | mm/min | 48000 | | Fast feedof Z axis | mm/min | 48000 | | Position accuracy | mm | 0.005/300mm | | Repeated accuracy | mm | 0.003/300mm | | Principal axis |
| | Distance from spindle nose to worktable | mm | 120-520 | | Distance from spindle center to main column | mm | 710 | | Axis cutting feed rate | mm/min | 1-8000 | | Motor power of XYZ axes | kw | 2 | | Spindle speed (standard) | rpm | 50-12000 | | Spindle speed (special) | rpm | 50-15000 | | Spindle motor | HP | 7.5 | | Spindle end specification |
| BT-30 | | Worktable |
| | Bed dimension | mm | 600*400 | | Max weigh | kg | 300 | | T groove number |
| 3 | | T groove size | mm | 14 | | Tool magazine |
| | Automatic tool changer | TYPE | Clamp arm tool | | Cutting tools number | PCS | 14 | | Others |
| | Controller |
| MITSUBISHI,FANUC: | | Cutting pump | HP | 2021/1/2 | | Electricity demand | kva | 20 | | Air pressure | kg/cm2 | 6-7bra | | Machine tool weight | kg | 3200 |
|
|
