| Configuration | Standard configuration |
| System | FANUC |
| Maximum rotating diamete | Φ400mm |
| Maximum workpiece length/diameter | 300mm/Φ320mm |
| Maximum diameter of bar | 42mm |
| Spindle head form | A2-5GB/T5900 1 |
| Diameter of spindle bore | Φ56mm |
| Maximum speed of spindle(r/min) | 5000rpm |
| Power of spindle motor | 5.5/7.5KW |
| three-jaw chuck/Hollow Rotary oil cylinder | 6#/6# |
| Spindle Strvel of X/Z-axis | 160/400mm |
| Rapid speed of X/Z-axis | 24/30mm |
| Motor torque of X/Z-axis | 9NM/12NM(mm) |
| Tool number | 8 |
| Tool specifications (turning/hole) | 20*20(φ25)mm |
| Horsepower mode | Hydraulic |
| Tailstock sleeve（Diameter/stroke/inner hole） | Φ62mm/100mm/MT4 |
| tailstock sleeve(Horsepower mode/movement mode) | Hydraulic program control, manual movement |
| Repeat positioning accuracy (X/Z) | 0.005mm |
| Turning | 0.002mm |
| Consistency of cutting diameters | 0.006/100mm |
| Surface roughness | 0.4（Nonferrous metals ） |
| Layout form of machine tool body | 30 ° inclined bed |
| Weight | 3000KG |
